• Spicer 35 spline SAE-4340 nickel chromoly steel axle shafts
• Axle tubes: 3.5" outside diameter/.390" (rear) wall thickness
• Spicer ring and pinion gearing: 9.75" (248 mm) on rear
• Genuine “Made in the USA” gearing
• Heavy-duty 8" x 6.5" wheel bolt pattern
• Nodular iron diff cover
• Selectable electronic locking differentials
• Heavy-duty brackets
• Spicer 1350 strap-style/half-round end yoke
• Upgraded heavy-duty brakes with plug-and-play ABS system

Specifications

• Axle Style: Full Float
• Axle Type: Dana 60
• Bolt Pattern: 8x6.5
• Ratio: 3.73
• Ring Gear: 9.75in Ring and Pinion
• Spline Count: 35
• Tubing Diameter: 3.50in
• Width: 69in

Warranty: 1 Year Limited

Fitment: JT
